REDEX® Slide

Active isolation of abrasive media.

REDEX® Slide
Whether it is silos, mills or extraction systems, our slide valves enable a safe isolation, and are also available for demanding CIP, dust or gas applications. The REDEX® slide valve is suitable for the isolation of fully developed explosions to the maximum explosion pressure.
The REDEX® Slide is available nominal pipe sizes from DN 50 to DN 150. Thanks to its practical design, the knife gate valve is suitable for all flow velocities and dust loads, it does not cause any pressure drop, and can be installed vertically, horizontally or at any angle.
REDEX® Slide with Accessoires

revision set

reactivation kit

  • Variably applicable.
  • Extremely short closing times.
  • Short installation distances thanks to a compact design.
  • Flexible installation options at any angle.
  • No loss of pressure.
The system to be protected is equipped with pressure and/or infrared detectors. These can detect an explosion and send a signal to the knife gate valve. Depending on the size, one or more gas generators are activated, which close the slide valve due to the generated pressure. The closed slider blade effectively prevents the propagation of flames and pressure waves. Fast closing times also enable extremely short installation distances. During normal operation, the slide valves can be opened and closed pneumatically.
Technical data
Product parameters
active action: slide valve gets closed by gas generator
DN 50 - DN 150
for low or medium pressure, no pressure drop in the pip
Dust load
for low or high dust load, the slide valve is no obstacle in the pipe
for organic dusts
Flow velocity
for low or high flow velocity, over 25m/s
Prozess temperature
for low pressure temperature, up to 100 °C
Mode of operation
single acting, double acting
Installation position
any installation position, vertical, horizontal or in any other angle
Applications + Industries
  • aspiration plants
  • brewery
  • chemical industry
  • chemical- petrochemical
  • food
  • food production
  • mills and grinding plants
  • mixers
  • pharmaceutical industry
  • recycling
  • silo


Certified in
accordance with

EN 15089
ATEX EC type examination certificate no. FSA 17 ATEX 1669 X

ATEX EC type
examination certificate no. FSA 17 ATEX 1669 X

ATEX EC type examination certificate no. FSA 14 ATEX 1647 X

ATEX EC type
examination certificate no. FSA 14 ATEX 1647 X

Explosion slide valves are also particularly suitable for abrasive media.

Click and drag image to view.

Scan the QR code with your iOS camera* to see an AR preview of the product.
REDEX AR Viewer Ru
The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
