Explosion vent
for hygienically
demanding ­processes
.

ERO

for low to medium pressure + alternating pressure.

REMBE® ERO
Made in Germany
Specially developed for production plants with strict hygiene requirements, REMBE® ensures increased safety + cleanliness with the ERO explosion vent.
Application
The ERO sanitary vent panel is used in the pharmaceutical, chemical and food industry in a broad range of system areas. The smooth and closed stainless steel membrane which faces the process, optimally seals the vessel and enables sterilization of the vent panel while still installed. The hygienic and robust design enables a reliable response, even at the lowest burst pressures. The working pressure is at 75% of the minimum burst pressure.
REMBE ERO with Accessoires

RSK signalling unit

The retrofit signaling unit with tear wire.

BIRD signalling unit

Contains a ceramic bar with integrated electrical conductors, also for high temperatures.
Advantages
  • The only vent panel with USDA approval.
  • Easy and safe to maintain sterile through the special design of the ERO.
  • Easy installation and low maintenance effort.
Mechanism
In case of a sudden pressure increase, the ERO vent panel will open and release the pressure from the vessel.
Technical data
Product parameters
Standard burst pressure Pstat
0,1 bar at 22 °C
Max. permitted operating pressure
75 % of Pstat
Temperature
-40 bis +180 °C (seal dependent)
Material
Stainless steel
Gasket material
silicone, EPDM
Tolerance
± 25 % at standard burst pressure
Standard vacuum resistance
Available on request, depends on diameter nominal and geometry
Our specialists will be pleased to assist you in finding a solution that matches your specific operating conditions.
Applications + Industries
  • animal feed productions
  • aspiration plants
  • brewery
  • destoners
  • filters
  • food
  • food production
  • mills and grinding plants
  • mixers
  • pharmaceutical industry
  • screens
  • silo
  • spray dryers
  • wood processing

Certifications

SIL-Equivalent

SIL 4

Approval

USDA
ATEX EC type examination certificate no. FSA 04 ATEX 1538 X

ATEX EC type
examination certificate no. FSA 04 ATEX 1538 X

In conjunction with the Q-Rohr®, the rupture disc ERO enables flameless pressure relief even in hygienically demanding applications.

REMBE® ERO

Application in the milk insustry.

REMBE® ERO

Application in the milk insustry.
Click and drag image to view.

Scan the QR code with your iOS camera* to see an AR preview of the product.
ERO AR Viewer Ru
The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
