Made in Germany
Filters with high vacuum requirements and large vent areas are protected with the MDX vent panel. With a standard burst pressure of 0.05 bar at 22°C, the MDX can also be used in other system components with a medium to high pressure, as well as for vacuum and alternating pressures. Its unique one-piece design provides a combination of precise opening behaviour with a high vacuum resistance and the lowest possible weight per surface area unit.
REMBE MDX with Accessoires

RSK signalling unit

The retrofit signaling unit with tear wire.

BIRD signalling unit

Contains a ceramic bar with integrated electrical conductors, also for high temperatures.
  • Reduction of deposits: the design guarantees high pressure resistance without the need for an extra vacuum support.
  • Weight savings through three-dimensional reinforcement corrugations.
  • Low initial purchase costs: single-layer vent panel.
In case of a sudden pressure increase, the MDX vent panel will open and release the pressure from the vessel.
Applications + Industries
  • animal feed productions
  • aspiration plants
  • brewery
  • destoners
  • filters
  • food
  • food production
  • mills and grinding plants
  • mixers
  • screens
  • silo
  • spray dryers
  • wood processing

The design of the MDX makes it the ideal vent panel, even under high vacuum, lowest burst pressure and alternating pressures.

Click and drag image to view.

Scan the QR code with your iOS camera* to see an AR preview of the product.
MDX AR Viewer Ru
The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
