ODV, ODU

for high to full vacuum and pressure cycling.

REMBE® ODV, ODU
Made in Germany
The REMBE® ODV comprises three explosion vent elements, a top section burst element, a sealing membrane and an integrated vacuum support. The ODU is ideal for applications that involve pressure cycling but no vacuum. In this version, the vacuum support used on the ODV is replaced by a supporting lower section.
Application
ODV explosion vent is used under demanding vacuum to overpressure cyclic operating conditions. Designed for working pressures of up to 80 % of static burst pressure. The ODV is ideal for use in applications such as filters with frequent jet-pulse cleaning, high vacuum or suction conveyors. It is vacuum resistant and the standard explosion pressure is 0.1 bar at 22 °C (71.6 °F).
REMBE ODV, ODU with Accessoires

SK signalling unit

uses the closed-circuit current principle.

Seal

The seals are available for all process conditions: Also suitable for high temperatures or sterile requirements.

Mounting frame and flange

for your rupture disc, available in Galvanised or stainless steel.
Advantages
  • Low response pressure with full vacuum resistance is possible.
  • High working pressure resistance of the explosion vent offers maximum productivity for your processes.
  • Triple-section domed construction ensures high-pressure cycling resistance and exceptional service life.
  • Round versions and special customised solutions possible.
Mechanism
When pressure rises, the explosion vent opens at the defined breaking point and releases pressure out of the vessel into the surrounding area.
Technical data
Product parameters
Standard burst pressure P Pstat
0,1 bar
Max. permitted operating pressure
80 % of Pstat
Temperature
− 100 to + 230 °C (− 148 to + 446 °F)
Material
Stainless steel
Tolerance
± 15 % at standard burst pressure
Our specialists will be pleased to assist you in finding a solution that matches your specific operating conditions.
Applications + Industries
  • animal feed productions
  • aspiration plants
  • brewery
  • destoners
  • filters
  • food
  • food production
  • hydrogen
  • mills and grinding plants
  • mixers
  • recycling
  • screens
  • silo
  • spray dryers
  • wood processing

Certifications

SIL-Equivalent

SIL 4
ATEX EC type examination certificate no. FSA 04 ATEX 1538 X

ATEX EC type
examination certificate no. FSA 04 ATEX 1538 X

REMBE® ODV, ODU
REMBE® ODV, ODU
Click and drag image to view.

Scan the QR code with your iOS camera* to see an AR preview of the product.
ODV ODU AR Viewer Ru
The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
