STAR

for low to high pressures.

Low profile - High Performance.

STAR is a three-section solution primarily used in applications with low to high response pressures, especially in the oil and gas industry, petrochemicals and chemicals, applications with liquified gases and processes that involve pressure cycling. The standard operating ratio is up to 80 %* of the minimum response pressure. Extremely tight tolerances of +/- 5 % are possible. For applications with a burst pressure of less than 1 barg, STAR can be installed directly between flanges.

* Depending on the specific application.

The advanced manufacturing process guarantees minimum fragmentation when opening even at the highest pressures. Its star-shaped opening pattern is flatter than that of other rupture discs so it requires less installation height. The integrated vacuum support guarantees high vacuum resistance.

signalling devices

Automated processes use intelligent signalling systems to keep you informed at all times about the status of your entire plant and any faults that may arise. You can even install signalling devices for rupture discs that have already been installed.

product overview

rupture disc holder

REMBE^® guarantees you a perfect installation and optimal function of your bursting disc. Due to the special design of the various REMBE^® rupture disc holders, incorrect installation of the associated rupture disc is impossible.

Cost-effective, durable solution.

STAR comprises three layers, a top section, a sealing membrane and an integrated vacuum support. As the critical burst element is not in contact with the process media, this can be sourced in less exotic materials enabling the STAR rupture disc to be a cost-effective solution even for the most corrosive operating conditions. The sealing membrane ensures high leak integrity of the disc, reducing the risk of loss of process media during normal operating conditions. Using a metallic seal ensures the long-term robustness and performance of the rupture disc even where harsh process media is present. The integrated vacuum support guarantees high vacuum resistance. The material selection of this rupture disc is fully customisable to best meet process onditions and budget requirements.

Low profile solution limits installation damage.

The low-profile solution enables simpler installation, reducing the risk of dome damage during installation and maintenance schedules. Low-profile solutions can reduce holder costs, further enhancing the affordability of this solution. REMBE^®’s advanced manufacturing and design process for the the STAR rupture disc ensures fragmentation is kept to a minimum upon burst even when operating under the highest burst pressures. Available from 25 mm to 600 mm STAR is mounted into REMBE^® IG-HL rupture disc holder for installation into industry standard flange arrangements*. Compatible with a range of REMBE^® signalling devices including its advanced NIMU, for reliable notification of disc burst. STAR is a versatile rupture disc offering superior performance across a range of demanding process conditions.

* Can be installed directly between flanges dependent on burst pressure and process conditions.

Advantages

Durable, low-profile solution: ensures superior performance and long life-cycle even where pressure-cycling or vacuum conditions are present.
Corrosion resistant and cost-effective: the critical burst element is not in contact with the process medium and can be sourced in different materials reducing overall cost without affecting performance.
Unique star-shaped construction: low profile enables simpler installation and reduced holder costs.
Minimal risk of fragmentation: even at high burst pressures.

Technical data

Product parameters

Feature	Characteristics	Variations
Holder compatibility	✓	G-HL, Flange, IG-HP, IG(-S), Threaded Holder,U-Holder
Signalling available	✓	NIMU, SIGU, BT-S, FOS, SB-(S), SBK-S
Pulsating, Cycling	✓	-
Vacuum resistance	absolute	-
Back pressure resistance	✓	-
K_RG (ASME) 2	2	-
K_RL (ASME) 2	2	-
Torque independent burst pressure	✓	-
Tolerance \| %	± 10 (±5, -0/+10, +0/-10 on request)	-
Manufacturing design range \| %	0	-
Operating ratio \| %	80	-
Non-fragmenting design	✓	-
Temperature range \| °C	-80 to 600*	-
Leakrate \| mbar l s^-1	10^-4 bis 10^-5	-

* Temperature limits for PED certification may vary.

Product parameters

Material	min. °C	max. °C
Inconel	-196	450*
Hastelloy	-196	400
Monel	-10	425
Nickel	-10	600
Stainless steel	-80	320
Titanium	-10	300
Tantalum	-10	250
PTFE	-79	230
FEP	-10	200

* Temperature limits for PED certification may vary.

Applications

autoclaves
chemical industry
chemical reactors
condensers
desalination plants
distillation towers
flare stacks
food production
FPSO applications
gas compressor modules
gas turbines for power generation
gas-tight pressure vessels
geothermal energy
heat exchangers
high pressure applications
isolation of safety valves
LDPE (thermoplastic)
LNG
mixers
oil and gas separation and treatment
petrochemical plants
power plants
process vessels
reactors
refineries
reverse osmosis systems
separators
silo
spray dryers
water injection pumps

Industries

brewery
chemical- petrochemical
food
hydrogen
oil and gas industry

Process medium	Suitability
Gas \| Steam	✓✓
Liquid with gas cushion	✓✓
Two phase flow	✓✓
Hygienic applications	✓✓

✓✓ recommended
✓ suitable

Downloads

Certifications

Works Certificate

PED

ASME

KOSHA (South Korea)

CML (China)

TR CU (EEU)

Click and drag image to view.

view in AR

Scan the QR code with your iOS camera* to see an AR preview of the product.

The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
